Bravilor Bonamat B20 W L/R Series

Bravilor Bonamat B20 W L/R Series


Round filtering machine to be mounted onto the wall for locations with water connection. The B20 W brews large quantities of coffee into separate containers. Equipped with digital display, total and day counters, descale system, coffee-is-ready signal, built-in timer and optimum security provisions. Including container(s) type VHG, filter unit(s) and wall console for brewing column.

Model with 1 brewing system and 1 container of 20 litres (left or right of the column). This enables you to easily compile, for example, double or triple machines.

Please note that the trolley and tip-up plate are not included as standard. These accessories can be ordered separately.

Strong points

  • Quickly large quantities of fresh filter coffee.
  • Robust and high-quality appearance because of stainless steel housing.
  • Equipped with coffee-is-ready signal, total and day counters and built-in timer.
  • Descale system and optimum security provisions.
  • Coffee of a consistent quality: The containers monitor the quality of the coffee.
Out of stock


  • Coffee
Buffer stock
  • 20 liter
Buffer stock coffee
  • 20 liter
Hour capacity
  • 90 liter
Brewing time
  • 14 minutes
Water connection
  • 400V 3N~ 50/60Hz 9120W
  • 400V¯3N 50/60Hz 9120W
Dimensions wxdxh
  • 742x570x888 mm
Article number
  • 4.321.801.110 with brewing basket
  • 4.321.901.110 B20 W L/R
